Plastic Enclosure Boxes Dual Door

It is swing out panel type and panel is easy to open or close as it will be assembled with handle and hinge type.This swing out panel is for our Nema 4X enclosure and very strong as it is fixed with 4 supports and has good external appearance.

หมวดหมู่ : Dual Door

1. It is swing out panel type and panel is easy to open or close as it will be assembled with handle and hinge type.
2. This swing out panel is for our Nema 4X enclosure and very strong as it is fixed with 4 supports and has good external appearance.

Level of dustproof and waterproof  IP 66/67
Impact test IK 07/08
Temperature rangeABS : - 40 ~ + 70 │ PC : - 40 ~ + 110
Flammability RatingABS : 94-HB │PC : 94-V-0, 94-HB

Swing Frame applicable modelModel
SizeModelDual door
(Frame, support, hinge, handle included)
Dual door mounting plate
(Aluminium)
W X L X H (mm)
200x300x130BC-ㅁㅁP-203013BC-F203013BC-FA2030
200x300x150BC-ㅁㅁP-203015BC-F203015BC-FA2030
200x300x180BC-ㅁㅁP-203018BC-F203018BC-FA2030
250x350x150BC-ㅁㅁP-253515BC-F253515BC-FA2535
250x350x180BC-ㅁㅁP-253518BC-F253518BC-FA2535
280x280x130BC-ㅁㅁP-282813BC-F282813BC-FA2828
280x380x130BC-ㅁㅁP-283813BC-F283813BC-FA2838
300x300x150BC-ㅁㅁP-303015BC-F303015BC-FA3030
300x300x180BC-ㅁㅁP-303018BC-F303018BC-FA3030
300x400x150BC-ㅁㅁP-304015BC-F304015BC-FA3040
300x400x180BC-ㅁㅁP-304018BC-F304018BC-FA3040
350x450x160BC-ㅁㅁP-354516BC-F354516BC-FA3545
350x450x200BC-ㅁㅁP-354520BC-F354520BC-FA3545
400x500x160BC-ㅁㅁP-405016BC-F405016BC-FA4050
400x500x200BC-ㅁㅁP-405020BC-F405020BC-FA4050
400x500x200BC-ㅁㅁH-405020BC-F405020BC-FA4050
400x600x180BC-ㅁㅁP-406018BC-F406018BC-FA4060
400x600x230BC-ㅁㅁP-406023BC-F406023BC-FA4060
400x600x230BC-ㅁㅁH-406023BC-F406023BC-FA4060
530x630x185BC-ㅁㅁP-506018BC-F506018BC-FA5060
530x630x255BC-ㅁㅁP-506025BC-F506025BC-FA5060
