ILME Multipole Connectors

Female insert, CNE series, screw terminal connection, 24 poles + PE, 16 A 500 V 6 kV 3, size "104.27", with plate

฿ 0 ฿ 0

Female insert, CNE series, screw terminal connection, 16 poles + PE, 16 A 500 V 6 kV 3, size "77.27", with plate

฿ 0 ฿ 0

Male insert, CNE series, screw terminal connection, 16 poles + PE, 16 A 500 V 6 kV 3, size "77.27", with plate

฿ 0 ฿ 0

Male insert, CNE series, screw terminal connection, 24 poles + PE, 16 A 500 V 6 kV 3, size "104.27", with plate

฿ 0 ฿ 0

Male insert, CDSH series, SQUICH® spring terminal connection without tools, 42 poles + PE, 10 A 400 V 6 kV 3, size "104.27

฿ 0 ฿ 0

Female insert, CDSH series, SQUICH® spring terminal connection without tools, 42 poles + PE, 10 A 400 V 6 kV 3, size "104.27

฿ 0 ฿ 0
New

เครื่องมือตั้งระดับตำแหน่งขา

฿ 0 ฿ 0
New

เครื่องมือย้ำแบบแมนนวล ไม่มีตัวกำหนดตำแหน่ง สำหรับหน้าสัมผัสแบบหัน 10 A และ 16 A

฿ 0 ฿ 0

ILME CONNECTORS ปลั๊กตัวผู้ ซีรีส์ CKS ต่อขั้วต่อสปริง 4 ขั้ว + PE 10 A 400 V 4 kV 3 ขนาด "21.21"

฿ 0 ฿ 0

ILME CONNECTORS ปลั๊กตัวเมีย ซีรีส์ CKS ขั้วต่อสปริง 4 ขั้ว + PE 10 A 400 V 4 kV 3 ขนาด "21.21"

฿ 0 ฿ 0

ILME CONNECTORS ปลั๊กตัวผู้ ซีรีย์ CKS ข้อต่อสปริง 3 ขั้ว + PE 10 A 400 V 4 kV 3 ขนาด "21.21"

฿ 0 ฿ 0

ILME CONNECTORS ปลั๊กตัวเมีย ซีรีส์ CKS ขั้วต่อสปริง 3 ขั้ว + PE 10 A 400 V 4 kV 3 ขนาด "21.21"

฿ 0 ฿ 0

The ILME TCHI-06L T-Type bulkhead mount insulating housing is size 44.27 and features a single lever. The body is thermoplastic with a thermoplastic lever. Insert center distance: 44 x 27 mm. Rated IP 65 when attached and locked down. The TCHI-06L offers a cost effective solution for many applications and withstands exposure from most chemicals, making it useful under more harsh conditions.

฿ 0 ฿ 0
New

The ILME TCHC-06L T-Type insulating rectangular cover is size 44.27 and has 2 pegs. The body is thermoplastic. Insert center distance: 44 x 27 mm. Rated IP 65 when attached and locked down. The TCHC-06L is used with other 44.27 T-Type enclosures and can withstand chemical exposure.

฿ 0 ฿ 0

The ILME TCHC-16 T-Type insulating rectangular cover is size 77.27 and has 4 pegs. The body is thermoplastic. Insert center distance: 77.5 x 27 mm. Rated IP 65 when attached and locked down. When used with a thermoplastic housing, the TCHC-16 stands up to exposure from most chemicals.

฿ 0 ฿ 0

The ILME TCHC-10 T-Type insulating rectangular cover is size 57.27 and has 4 pegs. The body is thermoplastic. Insert center distance: 57 x 27 mm. Rated IP 65 when attached and locked down. When coupled with a thermoplastic housing, the TCHC-10 is useful in harsh applications, due to its ability to withstand chemical corrosion.

฿ 0 ฿ 0
New

The ILME TCHI-24 C-Type bulkhead mount insulating housing is size 104.27 and features two levers. The body is plastic with thermoplastic levers. Insert center distance: 104 x 27 mm. Rated IP 65 when attached and locked down. The TCHI-24 is a cost effective solution to a wide variety of applications. It is resistant to corrosion and is ideal for working under extreme conditions.

฿ 0 ฿ 0
New

The ILME TCHI-16 T-Type bulkhead mount insulating housing is size 77.27 and features two levers. The body is plastic with thermoplastic levers. Insert center distance: 77.5 x 27 mm. Rated IP 65 when attached and locked down. The TCHI-16 is a cost effective solution for a number of applications. It is resistant to corrosion and is especially suited for working under extreme conditions.

฿ 0 ฿ 0

The ILME TCHI-10 T-Type bulkhead mount standard housing is size 57.27 and features a double lever. The body is plastic with thermoplastic levers. Insert center distance: 57 x 27 mm. Rated IP 65. Being plastic, the TCHI-10 is a low cost solution compared to metal housings. It is useful in harsh applications, due to its ability to resist corrosion from chemicals.

฿ 0 ฿ 0
New

The ILME CHI-24 C-Type bulkhead mount standard housing is size 104.27 and features two levers. The body is epoxy coated die cast aluminum with polyamide handles and stainless steel levers. Insert center distance: 104 x 27 mm. Rated IP 66 when attached and locked down. The clamping force supplied by the CHI-24 is constant with a life expectancy of at least 500 cycles.

฿ 0 ฿ 0
New

The ILME CHI-10C C-Type bulkhead mount standard housing is size 57.27 and features 4 pegs. The body is die cast aluminum. Insert center distance: 57 x 27 mm. Rated IP 66 when attached and locked down. The CHI-10C is durable with a life expectancy over 500 cycles.

฿ 0 ฿ 0
New

The ILME CHI-16 C-Type bulkhead mount standard housing is size 77.27 and features two levers. The body is epoxy coated die cast aluminum with polyamide handles and stainless steel levers. Insert center distance: 77.5 x 27 mm. Rated IP 66 when attached and locked down. The clamping force supplied by the CHI-16 is constant with a life expectancy of at least 500 cycles.

฿ 0 ฿ 0
