Dual Door
1. It is swing out panel type and panel is easy to open or close as it will be assembled with handle and hinge type.
2. This swing out panel is for our Nema 4X enclosure and very strong as it is fixed with 4 supports and has good external appearance.
| Level of dustproof and waterproof | IP 66/67 |
| Impact test | IK 07/08 |
| Temperature range | ABS : - 40 ~ + 70 PC : - 40 ~ + 110 |
| Flammability Rating | ABS : 94-HB PC : 94-V-0, 94-HB |
| Swing Frame applicable model | Model | ||
|---|---|---|---|
| Size | Model | Dual door (Frame, support, hinge, handle included) | Dual door mounting plate (Aluminium) |
| W X L X H (mm) | |||
| 200x300x130 | BC-ㅁㅁP-203013 | BC-F203013 | BC-FA2030 |
| 200x300x150 | BC-ㅁㅁP-203015 | BC-F203015 | BC-FA2030 |
| 200x300x180 | BC-ㅁㅁP-203018 | BC-F203018 | BC-FA2030 |
| 250x350x150 | BC-ㅁㅁP-253515 | BC-F253515 | BC-FA2535 |
| 250x350x180 | BC-ㅁㅁP-253518 | BC-F253518 | BC-FA2535 |
| 280x280x130 | BC-ㅁㅁP-282813 | BC-F282813 | BC-FA2828 |
| 280x380x130 | BC-ㅁㅁP-283813 | BC-F283813 | BC-FA2838 |
| 300x300x150 | BC-ㅁㅁP-303015 | BC-F303015 | BC-FA3030 |
| 300x300x180 | BC-ㅁㅁP-303018 | BC-F303018 | BC-FA3030 |
| 300x400x150 | BC-ㅁㅁP-304015 | BC-F304015 | BC-FA3040 |
| 300x400x180 | BC-ㅁㅁP-304018 | BC-F304018 | BC-FA3040 |
| 350x450x160 | BC-ㅁㅁP-354516 | BC-F354516 | BC-FA3545 |
| 350x450x200 | BC-ㅁㅁP-354520 | BC-F354520 | BC-FA3545 |
| 400x500x160 | BC-ㅁㅁP-405016 | BC-F405016 | BC-FA4050 |
| 400x500x200 | BC-ㅁㅁP-405020 | BC-F405020 | BC-FA4050 |
| 400x500x200 | BC-ㅁㅁH-405020 | BC-F405020 | BC-FA4050 |
| 400x600x180 | BC-ㅁㅁP-406018 | BC-F406018 | BC-FA4060 |
| 400x600x230 | BC-ㅁㅁP-406023 | BC-F406023 | BC-FA4060 |
| 400x600x230 | BC-ㅁㅁH-406023 | BC-F406023 | BC-FA4060 |
| 530x630x185 | BC-ㅁㅁP-506018 | BC-F506018 | BC-FA5060 |
| 530x630x255 | BC-ㅁㅁP-506025 | BC-F506025 | BC-FA5060 |
