THB.391.A3C.L TH391 - In-line circular mini-joint connector type "I" IP68/IP69K

Product name (Series) TH391 - In-line circular mini-joint connector tipo "I" IP68/IP69K Product configuration In-line joint connector Number of poles 3 Type of connection screw with push-wire clamp (M3 - max. 0.5 Nm) Cable diameter min. - max. 7.0 mm - 13.5 mm Operating current max. 24A Operating voltage max. 450V AC Wire cross-section min. - max. (Stranded cable) 0.25 mm2 - 2.5 mm2

หมวดหมู่ : 3 POLE



 GENERAL DESCRIPTION
 Type of installation Joint connector (re-usable/re-accessible)
 Type of product (Family) TEETUBE® - In-line and junction circular connectors IP68/IP69K
 Product name (Series) TH391 - In-line circular mini-joint connector tipo "I" IP68/IP69K
 Product configuration In-line joint connector
 Type of Fixation With quick-fix mounting clip
 Colour Black (Plastic components) - Techno green (Rubber components)
 Outer dimension Φ 23 mm x 95 mm
 ELECTRICAL CHARACTERISTICS
 Number of poles 3
 Contact marking 1 - 3 - 4(E)
 Type of connection screw with push-wire clamp (M3 - max. 0.5 Nm)• Recommnded for cable of cross-section < 1.0 mm2.
 Operating current max. 24A
 Operating voltage max. 450V AC
 MECHANICAL CHARACTERISTICS
 Protection against solid/water (IP) IP68 (30m,2h)/IP69K
 Corrosion resistance Salt mist, 1.000 ore, 5% salt solutions, 35°C EN60068-2-11:2000, Test Ka (168h)
 CABLE CHARACTERISTICS
 Wire cross-section min. - max. (Stranded cable) 0.25 mm2 - 2.5 mm2• Tested positively with cables of cross-section 0.25 mm2..
 Wire cross-section min. - max. (Solid cable) 0.25 mm2 - 2.5 mm2• Tested positively with cables of cross-section 0.25 mm2..
 Cable diameter min. - max. 7.0 mm - 13.5 mm• For cables with diameter For smaller cables please take the proper accessory.
 MATERIAL CHARACTERISTICS
 Connector housing PA66 GF UL94 V0 GWT 960°C
 Cable gland PA66 UL94 V2 GWT 850°C
 Sealing TPE
 Grommets TPE
 Contacts CuZn (nickel plated)
 Screws Steel (rivestimento Zinco)
 Material properties Halogen Free - Silicone Free
 T marking T 85°C
 Operating temperature range -40°C / +125°C
 Proof Tracking Index (PTI) PTI 250
