THB.392.A4A.R TH392 - Circular mini-junction connector 4 ways type "H" IP68

Product name (Series)TH392 - Circular mini-junction connector 4 vie tipo "H" IP68 Product configurationIn-line joint connector Number of poles4 Type of connectionscrew (M3 - max. 0.5 Nm) Cable diameter min. - max.5.0 mm - 12.0 mm (main cable) / 5.0 mm - 12.0 mm (branch cable) Operating currentmax. 17.5A Operating voltagemax. 450V AC Wire cross-section min. - max. (Stranded cable)0.5 mm2 - 4.0 mm2

หมวดหมู่ : Techno TEETUBE Series

 GENERAL DESCRIPTION
 Type of installation Joint connector (re-usable/re-accessible)
 Type of product (Family) TEETUBE® - In-line and junction circular connectors IP68/IP69K
 Product name (Series) TH392 - Circular mini-junction connector 4 vie tipo "H" IP68
 Product configuration In-line joint connector
 Type of Fixation With quick-fix mounting clip
 Colour Black (Plastic components) - Techno green (Rubber components)
 Outer dimension 28 mm x 54 mm x 80 mm
 ELECTRICAL CHARACTERISTICS
 Number of poles 4
 Contact marking 1 - 2 - 3 - 4(E)
 Type of connection screw (M3 - max. 0.5 Nm)
 Operating current max. 17.5A
 Operating voltage max. 450V AC
 MECHANICAL CHARACTERISTICS
 Protection against solid/water (IP) IP68 (30m,2h)
 Corrosion resistance Salt mist, 1.000 ore, 5% salt solutions, 35°C EN60068-2-11:2000, Test Ka (168h)
 CABLE CHARACTERISTICS
 Wire cross-section min. - max. (Stranded cable) 0.5 mm2 - 4.0 mm2
 Wire cross-section min. - max. (Solid cable) 0.5 mm2 - 4.0 mm2
 Cable diameter min. - max. 5.0 mm - 12.0 mm (main cable) / 5.0 mm - 12.0 mm (branch cable)
 MATERIAL CHARACTERISTICS
 Connector housing PA68 UL94 V0 GWT 960°
 Cable gland PA66 UL94 V2 GWT 850°C
 Sealing TPE
 Grommets TPE
 Contacts CuZn (nickel plated)
 Screws Steel (rivestimento Zinco)
 Material properties Halogen Free - Silicone Free
 T marking T 85°C
 Operating temperature range -40°C / +125°C
 Proof Tracking Index (PTI) PTI 250
