GW61016H STRAIGHT PLUG HP - IP44/IP54 - 2P+E - 63A - 200-250V 50/60HZ - BLUE - 6H - MANTLE TERMINAL

The IEC 309 HP system comprises plugs and socket-outlets from 16 to 125A in two different versions – straight mobile and 10° flush-mounting – available in protected versions with IP44/IP54 degree of protection and watertight versions with IP degree of protection of up to IP66/IP67/IP68/IP69

หมวดหมู่ : Straight plugs IP44/54

The IEC 309 HP system comprises plugs and socket-outlets from 16 to 125A in two different versions – straight mobile and 10° flush-mounting – available in protected versions with IP44/IP54 degree of protection and watertight versions with IP degree of protection of up to IP66/IP67/IP68/IP69 (the first and only on the electro-technical scene to have this). The introduction of all the clock references for the earthing contact completes the range for specific applications and installations. The 16-32A versions require screw or quick spring wiring, while the 63-125 A versions employ branching terminal connection technology.
Part Number GW61016H
Colour Blue
IP degree IP44/IP54
Mechanical resistance  IK09
Rated voltage 200 - 250 V
Frequency 50/60 Hz
Cable clamp tightening capacity 16.1-37 mm
Type of wiring  Mantle terminal
Electrocod 2210
Total number of operations > 2000
Breaking capacity at 1.1 Un 79 A
Thermo-pressure with ball 125 °C (active parts) - 80 °C (passive parts)
Rated current (A) 63
No. of poles 2P+E
Reference h 6
Type Straight plug
Terminal tightening capacity 6-16mm² flexible cables - 6-25mm² rigid cables
Operating temperature -25 +55 °C
Type of material  Halogen-free in compliance with EN 60754-2
Glow wire test 850 °C (active parts) - 650 °C (passive parts)
Insulation resistance > 10 MΩ
