XM10-S10S-C CM10-SP10S-M Straight Plug 10P EUMAX CM10 Connector

หมวดหมู่ : Servo Motor Connectors

Technical Data 2 Contacts
4 Contacts
Rated Current/Voltage3A/200VAC
Insulation Resistance1000M Ω /500VDC
Withstanding Voltage1500V AC/1minute900V AC/1minute
Contact MaterialGold-plate Copper Alloy
Matal Shell MaterialZinc Alloy Die-Cast
Coupling TypePush-Pull and Thread Coupling
IP ProtectionIP67
Wire Cross-Section16-20AWG20-28AWG
Working Temperature-25 °C to +85 °C



Ordering Information
Series
     XM10  Push-Pull Coupling
     XM10S Thread Coupling

Termination Type
     C Solder
     Black  Crimp



Type
     S Straight Plug
     A Angled Plug
     R Bulkhead Receptacle

Colour
     Black  Metallic
     BK  Black



Poles
     2S  2 Poles Plug,Socket
     10S
10 Poles Plug,Socket
     2P 2 Poles Receptacle, Pin
     10P 10 Poles Receptacle,Pin
