PLS-20 Series (Output Type) PLS Series Square Connectors
คุณสมบัติสินค้า:
Industrial & Waterproof series connectors product application are often preferred in Motors, Power, Electronics, Mechanical, Medical Equipment, MRT, Automobiles, Electric Vehicles, Communication Equipment, Military Applications, etc.
หมวดหมู่ : CONNECTORS , PLT Circular Industrial Connectors ,
แบรนด์ : PLT
| No. of contacts | 2 | 3 | 4 | 7 |
| Contacts Configuration |  |  |  |  |
| Rated current / Voltage | 15A 250V | 15A 250V | 10A 250V | 10A 250V |
| Operation Limit Voltage (AC.V.rms) | 250 | 250 | 250 | 250 |
| Withstanding voltage (AC.V.rms) 1 minute | 1500 | 1500 | 1500 | 1000 |
Insulation resistance (M MIN.) at DC 500V | 2000 | 2000 | 2000 | 2000 |
| Contact resistance (M MAX.) at DC 1A | 3 | 3 | 3 | 3 |
| Solder inter diameter | 1.8 | 1.8 | 1.6 | 1.6 |
| Model Reference | PLS-202-RF-R PLS-202-ADF-R PLS-202-AD(F)F-R PLS-202-ADGF-R PLS-202-ADGF(F)-R PLS-202-PM- X-R PLS-202-GPM3 X-R PLS-202-WGPM3 X-R | PLS-203-RF-R PLS-203-ADF-R PLS-203-AD(F)F-R PLS-203-ADGF-R PLS-203-ADGF(F)-R PLS-203-PM- X-R PLS-203-GPM3 X-R PLS-203-WGPM3 X-R | PLS-204-RF-R PLS-204-ADF-R PLS-204-AD(F)F-R PLS-204-ADGF-R PLS-204-ADGF(F)-R PLS-204-PM- X-R PLS-204-GPM3 X-R PLS-204-WGPM3 X-R | PLS-207-RF-R PLS-207-ADF-R PLS-207-AD(F)F-R PLS-207-ADGF-R PLS-207-ADGF(F)-R PLS-207-PM- X-R PLS-207-GPM3 X-R PLS-207-WGPM3 X-R |
