OSF 40
Splitable cable glands
OSF 40 is a divisible cable gland with metric threads particularly suitable for use with cables with connectors.
OSF 40 can be equipped with two small(SPC) or multiple cable grommet holders for cables from 2 to 14 mm in diameter.
Features
- Metric thread M40
- Snap-in assembly
- IP54
- Locknut included
- Available colors: grey and black
- halogen-free, silicone-free,flame class V0 both colors, comply with ASTM IRM 903 , UL 157
Material: PC
Flammability: self-extinguishing according to UL94-V0
Temperature: -40°C… +130°C (static)
Compatible Grommets
 SPC |  SPC 2x |  SPC 4x |
Fastening of the grommet strip to the board or panel is done with screws or rivets. Upon request, we supply screws for fastening, again made of stainless steel but with a black geomet finish. Alternatively, you can use the "Snap" quick coupler for greater mounting flexibility.
